CATGEN-EN

GENERAL CATALOGUE SOLUTIONS FOR PNEUMATIC AUTOMATION 2021

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 1 This catalogue includes the product range manufactured by Pneumax Industrial Automation Business Unit: air service units and pneumatic components for air distribution and motion control. General catalogue Solutions for pneumatic automation Further documentation is available on our website www.pneumaxspa.com with reference to Vacuum Technology, Fittings, Electric Actuation and general catalogues which include the product range offered by Automotive and Process Automation Business Units.

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 2 Air distribution About Pneumax. 12 Introduction General index Solutions for pneumatic automation Section 01 Valves and solenoid valves Series 104 1.1 Series 105 1.12 Series 200 1.21 Series T200 1.54 Spool valves and solenoid valves Series 800 1.68 Series 888 1.77 Series 400 1.90 Series T400 1.109 Series 2100 Line-Flat-Base 1.123 Series 2400 Line-Flat-VDMA 1.139 Series 2600 Line-Flat-VDMA 1.162 Single and manifold versions, mechanical and manual or pneumatic command Series 300 1.178 Solenoid coils 1.193 Series M (mechanical) 1.196 Direct operated solenoid valves Series CNOMO 1.201 Series S 1.204 300-UL solenoid coils 1.206 Pilot valves, high flow rate performance 2/2 ways and 3/2 ways, version miniaturized available as well UL solenoid coils 1.206 Series 700 1.208 Series N776 1.221 Series T772-773 1.226 Poppet valves and solenoid valves Series T771 1.241 Series PVA 1.249 Series F300 1.253 3/2 & 2/2 valves and solenoid valves for compressed air and vacuum, with aluminium and technopolymer body. 2/2 pad valves, shutter seating inclined solenoid valves for fluids Series PVF 1.282 Series 514/N 1.283 Series T514 1.285 “Namur” valves and solenoid valves Series 514 1.290 Namur valves and solenoid valves according to standard ISO 5599/1 available in 3 sizes with M12 5/2, 5/3 connectors, aluminium and technopolymer body Series 515 1.297 Solutions for pneumatic automation General catalogue

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 3 Solutions for pneumatic automation General catalogue Series 1000 1.303 ISO 5599/1 valves and solenoid valves Valves and solenoid valves according to standard ISO 5599/1 available in 3 sizes with M12 5/2, 5/3 connectors, aluminium and technopolymer body Series 1000-M12 1.320 Series 600 1.327 Series 50-T50 1.349 Series 900 1.341 Series 55-TecnoFUN 1.354 Series 1750 - 1760 1.369 Series Mini-RAP 1.371 Flow control valves, quick exhaust valves, selectors, silencers, unidirectional valves, manifolds, blocking valves, economizers, gang mounting manifolds, spry valves Unidirectional and bidirectional blocking valves, aluminium and technopolymer versions, with G1/8”- G1/4”- G3/8”- G1/2” connections Pressure switches, impulse generators, timers, two hands safety valve, oscillator valve, signal amplifier, progressive start up valve, high-low pressure device Miniaturized logic function with technopolymer body: RFU, RP, VB, VSR, VS-or, VS-and, IP, AP, RP+IP, VB+RFU, VB+VSR Brass versions rod G1/8” & with technopolymer body and integrated gauge version Nichel plated brass compact fittings, with straight male adaptor Pneumatic circuit accessories Blocking valves Complementary valves Function fittings Miniaturised pressure regulators Compact fittings for lubrication Accessories Series 2700 - ISO15407-2 1.373 Series 2300 Enova 1.400 Series 2200 Optyma-S 1.421 Wide range of multipolar & serial system, available with main fieldbus protocol Series 2200 Optyma-Sc 1.448 Series 2500 Optyma-F 1.455 Valves and solenoid valve manifolds Series 2500 Optyma-T 1.486 Series 3000 1.520

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 4 Air treatment Section 02 Series AIRPLUS 2.1 Air service units Wide range of components for compressed air treatment, available in aluminium, technopolymer and steel, in several sizes with connections from 1/8” to 1” and flow rates up to 8000 Nl/m Series 1700 2.88 Series 1700 Steel line 2.159 Pressure switches Series DS 2.204. 1700 standard 2.172 Series 1700 2.208 Digital pressure switches and pressure gauges, panel mounting or manifold versions The proportional pressure regulators are available in 3 sizes, standard, CANopen® and IO-Link, or miniaturized versions 3 sizes aluminium pressure boosters available or technopolymer with 2:1 compression ratio Measuring devices Proportional technology Pressure booster Pressure gauges Series DS 2.206 1700 miniaturized 2.188 Series P+ 2.213 Series 1303-1304-1305-1306-1307 3.30 Cylinders manufactured according to standards CNOMO, CETOP and ISO: standard versions, through rod versions, tandem push with common rod, tandem push with independent rods or opposed tandem with common rod CNOMO-CETOP-ISO cylinders Pneumatic actuation Section 03 ISO 6432 Microbore cylinders Cylinders with piston rod according to standard Versions available: with threaded end caps, rolled end caps, aluminium, stainless steel and technopolymer versions Series 1200 3.1 Threaded end caps cylinders Series 1200 3.4 Rolled end caps (MIR) Series 1200 3.8 Rolled end caps (MIR-INOX) Series 1200 TECNO-MIR 3.10 Series 1200 Steel line 3.12 Series 1319-1320-1321 3.40 Series 1348-1349-1350 3.43 ISO 15552 cylinders Series Ecoplus 3.46 Series Ecolight 3.50 Cylinders according to ISO 15552 with bores from Ø32 to Ø200 mm and strokes up to 1250 mm. Available versions: ECOPLUS with aluminium or technopolymer end plates, ECOLIGHT optmized in weight and dimensions, Steel line completely in stainless steel, round tube versions tie rod (Ø250-Ø320 mm) Series 1315 Round tube 3.68 Series Inox Steel line 3.71 Series 1450-1463 3.81 ISO 15552 Hydro-pneumatic speed control cylinders with internal hydraulic circuit for movement control ISO 15552 Hydro-pneumatic speed control cylinders Solutions for pneumatic automation General catalogue

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 5 Series 1500 3.127 Series 6100-6101-6110 3.152 Series 6600 3.168 Short stroke & compact cylinders Guided compact cylinders Slide cylinders Short stroke & compact cylinders with bores from Ø20 to Ø100 mm, available in single and double acting versions, tandem and through rod with magnetic piston versions. The Europe version is compliant with the ISO or UNITOP standard (depending on bores), while the Europe-S versions have connections and rods accordingaccording to the ISO 15552 standard These cylinders are available in sizes Ø32 to Ø63 mm, and comprise a single compact cylinder with integral guide rods, The rod guide is available in two styles: self-lubricating bronze bushes and bearing bushes Slide cylinders manufactured with bores from Ø8 to Ø25 mm, with strokes up to 150 mm. Available with simple and double regulation end stroke and also with front and rear shock absorber Europe 3.136 Ecompact-S 3.144 Series 1400 3.115 Series 6500 3.149 Hydraulic speed control cylinders Multimount cylinders Hydraulic speed control cylinders outward/inward control, and lateral or in-line tank. Available with SKIP valve (accelerating device) and blocking valve (STOP) Multimount cylinders available with bores from Ø10 to Ø25 mm, with strokes up to 50 mm and with magnetic piston versions Series Ecompact 3.87 Series 3.105 1325-1326-1345-1347 Series ECOFLAT 3.108 Compact cylinders according to standard ISO with integrated slots suitable for sensors mounting without adaptors. Bores from Ø20 to Ø100 mm. Versions with end stroke adjustable pneumatic cushioning are also available according to ISO 21287 Non rotating cylinders twin rod version, available with bores from Ø32 to Ø100 and strokes up to 500 mm ECOFLAT cylinders available with sizes from 25 to 63 mm and strokes up to 300 mm. Profiled tube has two “T” slots to host sensors 1580._, MRS._, MHS._. without adaptors. Two additional connections are also available on rear cover for cylinder feeding ISO 21287 Compact cylinders Non rotating cylinders Flat cylinders Cylinders with Piston rod not according to standard Solutions for pneumatic automation General catalogue Series 1200 3.103 Special performance (1213-1273) Special performance microbore cylinders with hexagonal or round body and either completely threaded or threaded with a plain rod ending Threaded body microbore cylinders

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 6 Rack & pinion rotary actuators Rotary actuators Series 1330 3.213 Series 6400 3.217 Double or single rack & pinion rotary actuators Series 6411 3.221 Series 6420 3.225 Vane type rotary actuators with the shaft that runs into ball bearings, available with sizes from Ø10 to Ø100 mm Vane type rotary actuators Handling Series 6301 3.236 Series 6302 3.239 Pneumatic grippers Series 6303 3.242 Series 6310 3.245. Pneumatic grippers with 2 fingers angular opening (-10° to +30°), wide opening 180° or 3 parallel fingers Series 6311 3.248 Series 6312 3.251 Magnetic sensors Standard series Magnetic sensors with Reed type or Hall effect Series SA 3.254 Pneumatic actuation / Cylinders with piston rod not according to standard (following) Section 03 Series 6200 3.178 Slide units Series 6210 3.184 Series 6700 3.189 Twin-rod linear guide units with bores from Ø10 to Ø32 mm, and with control unit with bronze bush versions, with control unit with bearing bush versions. Are also available the through twin-rod slide units and the compact slide units Series 1600 Ø16 mm 3.207 Mechanically coupled Rodless cylinders Series 1605 3.196 Mechanically coupled cylinders with bore from Ø16 to Ø63 mm, and strokes up to 6000 mm, available also with linear control unit Cable driven Series 1601 3.212 Cable driven cylinders with cable linear translation system Solutions for pneumatic automation General catalogue

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 7 Series SR 3.263 Series SU CURS 3.264 Miniaturized series Series SQ 3.265 Miniaturized series with Reed and Hall style versions, available with rectangular, square, square section CURS approved, and round section versions Series ST 3.266 Solutions for pneumatic automation General catalogue Piston rod lock Accessories and fixing devices Series 1260 - 1320 3.269 Piston rod lock for cylinders with bores from da Ø12 to Ø125 mm Series 1260 - 1320 3.271 Series 6900 3.273 Linear control units Series 1200 (Ø20-25 mm) and Series 1320 (da Ø32 a Ø80 mm) Shock absorbers with M8x1 - M10x1 - M14x1,5 - M20x1,5 - M27x1,5 threads Linear guides Shock absorbers Appendix A Pneumatic symbols Dimensioning Unit of measure, conversion tables Alphanumeric index A.1 A.4 A.13 A.17

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 8 Solutions for pneumatic automation General catalogue

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 9 Technologies and competence since 1976 The excellence of Made in Italy in the world for over 40 years Founded in 1976, PNEUMAX S.p.A. is now one of the major international producers of components and systems for automation, leader of the Group of the same name made up of 25 sales and production companies that employ 730 collaborators throughout the world. Continuous investments in research and development have allowed Pneumax to broaden its offer of standard products and customised solutions implementing not only the consolidated pneumatic technology but also electrical actuation and fluid control components. The aim to offer increasingly specialised services and applicative competences has led to the creation of 3 dedicated Business Units, respectively industrial automation, process automation and automotive. AUTOMOTIVE PROCESS AUTOMATION INDUSTRIAL AUTOMATION Solutions for pneumatic automation General catalogue

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 10 Through a network comprised of branches and exclusive distributors, Pneumax operates in over 50 countries around the world, to support its customers throughout every stage of the supply process, from applicative pre-sales analysis to after-sales assistance. Pneumax target has always been to provide a complete service both in the pre-sales and after-sales service phases all over the word. The Pneumax network reflects corporate values and vision and at the same time enhance the peculiarities of the different markets and sectors in which it operates. Constant investments aimed at strengthening structures, technologies and skills make Pneumax a real technological partner. Human competence and smart technology represent the essential combination for the creation of quality products. An international network Headquarters Branches Distributors Think Global Act Local The certainty of a partner always by your side Solutions for pneumatic automation General catalogue

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 11 PRODUCT SPECIALISTS Specific knowledge • Products and Technologies BUSINESS SPECIALISTS Dedicated competences • Sectors and Applications SALES ENGINEERS Worldwide Presence • Relationship management Pneumax Business Attitude Headquarters PNEUMAX An operational model that stems from the capacity to combine sectorial, technological and applicative competences through the collaboration of customers with our industry Business Specialists and with Product Specialists focused on products and technologies, the most effective solutions are created considering the TCO (Total Cost of Ownership) relative to the product’s entire life cycle. 23 Branches 62 Distributors 8 Production units Solutions for pneumatic automation General catalogue

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 12 Pneumax’s technological offer includes various technologies, from pneumatic actuation to electrical actuation, to components for the control of liquid and gaseous fluids, to offer the best solution in every applicative context. Products and Technologies The value of the solution Pneumatic technology Electric actuation Fluid control • Mechatronic Solutions • Integrated cabinets and systems • Special Processing • Custom Treatments • Special Materials • Customised testing procedures Special Solutions Services and Products The supply of custom solutions has always been Pneumax’s flagship service. Experience, competence, organisation and use of the most advanced production technologies are at the base of the capacity to offer customised products and services designed and created to fulfill the needs of every single customer. Solutions for pneumatic automation General catalogue

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 13 Industrial automation The Business Unit that produces components and systems for industrial automation represents the core of Pneumax Spa. Founded to create pneumatic components, the company has constantly invested to broaden the offer of products and technologies, implementing not only the consolidated pneumatic actuation but also electrical actuation and fluid control components. Process automation The desire to develop the range of products suitable for use in “process” related sectors that require dedicated materials like stainless steel or special performance such as working pressure in Oil & Gas, has led Pneumax to create a Business Unit dedicated entirely to process automation. Automotive The Pneumax Automotive division offers a complete range of products dedicated to the production lines of the industry, with a special focus on Body in White applications. In fact Pneumax’s offer includes clamping units, pin packages, grippers, power pivots and complete multi axes positioning systems. Solutions for pneumatic automation General catalogue

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 14 At Pneumax, Total Quality is an “operating style” constantly nurtured by ongoing training at all levels and an awareness of shared “knowledge” as a corporate asset essential to the company’s success. Choosing to operate under a Total Quality System means implementing management methods and tools that involve all staff and enable constant monitoring of process efficiency and product quality, starting from the raw materials and the components necessary to make them and continuing through processing and assembly. Pneumax’s manufacturing operations are concentrated at the Lurano production facilities in the province of Bergamo while fittings are manufactured by Titan Engineering, a Pneumax Group Company located in San Marino.To ensure the greatest reliability for our customers, the best suppliers are selected, often right on-site, and mechanical processing is carried out inhouse by Supermeccanica another company belonging to the Pneumax Group. Total Quality Management The highest quality of products and processes guaranteed throughout the supply chain Solutions for pneumatic automation General catalogue

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 15 System and Product Certifications Product Certifications: SIL certificates of compliance with IEC 61508 standards UL Product in compliance with US standards EAC Certificate of conformity for the free circulation of products in the Euro-Asian Economic Community ISO 45001:2018 Health and safety management system CSA Product in compliance with Canadian standards Well Tried Components EN ISO 13849, suitable for application in safety circuits ISO 14001 Environmental management systems ISO 9001 Quality management system Compliance with Machinery Directive 2006/42/CE Compliance with ATEX 2014/34/UE directive Solutions for pneumatic automation General catalogue : Suitable up to SIL 3 : International certification for explosive atmospheres : UL / CSA Factory Mutual Approval : Nepsy approval - China : CU - TR 012 II 2G Ex h IIC Gb II 2D Ex h IIIC Db :

Le informazioni tecniche sono fornite solo a scopo informativo e possono essere soggette a modifiche senza preavviso 1|i Air distribution Valves, solenoid valves and devices for compressed air distribution and control Valves and solenoid valves Spool valves and solenoid valves Direct operated solenoid valves Single and manifold versions, mechanical and manual or pneumatic command Pilot valves, high flow rate performance 2/2 ways and 3/2 ways, miniaturized version available as well Section 01 Solutions for pneumatic automation General Catalogue Series 104 1.1 Series 105 1.12 Series 200 1.21 Series T200 1.54 Series 800 1.68 Series 888 1.77 Series 400 1.90 Series T400 1.109 Series 2100 Line-Flat-Base 1.123 Series 2400 Line-Flat-VDMA 1.139 Series 2600 Line-Flat-VDMA 1.162 Series 300 1.178 Solenoid coils 1.193 Series M (Mechanical) 1.196 Series CNOMO 1.201 Series S 1.204 300-UL solenoid coils 1.206 UL solenoid coils 1.206 Air distribution Index

Le informazioni tecniche sono fornite solo a scopo informativo e possono essere soggette a modifiche senza preavviso 1|i Accessories Poppet valves and solenoid valves “Namur” valves and solenoid valves ISO 5599/1 valves and solenoid valves Pneumatic circuit accessories Complementary valves Blocking valves Function fittings 3/2 & 2/2 valves and solenoid valves for compressed air and vacuum, with aluminium and technopolymer body. 2/2 pad valves, shutter seating, angle seated solenoid valves for fluids Namur valves and solenoid valves according to standard ISO 5599/1 available in 3 sizes with M12 5/2, 5/3 connectors, aluminium and technopolymer body Valves and solenoid valves according to standard ISO 5599/1 available in 3 sizes with M12 5/2, 5/3 connectors, aluminium and technopolymer body Flow control valves, quick exhaust valves, selectors, silencers, unidirectional valves, manifolds, blocking valves, economizers, gang mounting manifolds, spry valves Pressure switches, impulse generators, timers, two hands safety valve, oscillator valve, signal amplifier, progressive start up valve, high-low pressure device Unidirectional and bidirectional blocking valves, aluminium and technopolymer versions, with G1/8”- G1/4”- G3/8”- G1/2” connections Miniaturized logic function with technopolymer body: RFU, RP, VB, VSR, VS-or, VS-and, IP, AP, RP+IP, VB+RFU, VB+VSR Solutions for pneumatic automation General Catalogue Series 700 1.208 Series N776 1.221 Series T772-773 1.226 Series T771 1.241 Series PVA 1.249 Series F300 1.253 Series PVF 1.282 Series 514/N 1.283 Series T514 1.285 Series 514 1.290 Series 515 1.297 Series 1000 1.303 Series 1000-M12 1.320 Series 600 1.327 Series 900 1.341 Series 50-T50 1.349 Series 55-TecnoFUN 1.354 Air distribution Index

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 1|i Solutions for pneumatic automation General Catalogue Air distribution Index Accessories (following) Miniaturised pressure regulators Compact fittings for lubrication Brass versions rod G1/8” with technopolymer body and integrated gauge version Nichel plated brass compact fittings, with straight male adaptor Series 1750 - 1760 1.369 Series Mini-RAP 1.371 Wide range of multipole & serial systems, available with main fieldbus protocols Series 2700 - ISO15407-2 1.373 Series 2300 Enova 1.400 Series 2200 Optyma-S 1.421 Series 2200 Optyma-Sc 1.448 Series 2500 Optyma-F 1.455 Series 2500 Optyma-T 1.486 Series 3000 1.520 Valves and solenoid valve manifolds

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice Spool valves and solenoid valves Series 104 1 Air distribution 1 | 1 Series 104 General The micro valves 104 series are a cost effective solution with reduced overall dimensions, easy to install and manage. Their main characteristic is the possibility to choose between the version with lateral or rear pneumatic connections realized with quick fitting for Ø4mm tube included. The valves are available with 2 or 3 ways versions, normally closed or open, 5 ways and 5 ways 3 positions open centres and pressured centres. The 5 ways version is made with two 3 ways valves placed side by side with common inlet. The operators available for this valve are push button (different versions), selector (key, short and long lever), lever (lever roller or level undirectional) and pneumatic. It is also possible to combine the 2 and 3 ways valves with electrical switches, normally closed or open. Construction characteristics Body and cover Technopolymer Operators Plastic material for buttons and switches Seals NBR Spacer Technopolymer Spools Steel Springs Spring steel Pistons Aluminium (for pneumatic command version) Use and maintenance This valves have an average life of 15 million cycles depending on the application and air quality. Filtered and lubricated air using specified lubricants will reduce the wear of the seals and ensures long and trouble free operation. Please ensure that the valve is being used according with the manufacturers specification, such as air pressure and temperature. ATTENTION: use hydraulic oil class H for lubrication such as MAGNA GC 32 (Castrol). A : 2/2 N.C. B : 2/2 N.A. C : 3/2 N.C. D : 3/2 N.A.

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 1 Air distribution Spool valves and solenoid valves 1 | 2 Series 104 - Mechanical and manual command ►Tappet - Spring Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 90 Orifice size (mm) 2.5 Working ports size ø4 tube Coding: 104.T.0.1.W.F T TYPE 22 = 2 ways 32 = 3 ways W CONNECTION TYPE L = Lateral P = Rear F FUNCTION A = Normally Open C = Normally Closed 2/2 - 3/2 - Lateral connections Weight 20 g Operating force 13 N 104.T.0.1.L.F 1 2 2/2 - 3/2 - Rear connections Weight 20 g Operating force 13 N 104.T.0.1.P.F 1 2 1 2 ►Push button - Spring Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 90 Orifice size (mm) 2.5 Working ports size ø4 tube Coding: 104.T.6.22/C.W.F T TYPE 22 = 2 ways 32 = 3 ways 52 = 5 ways C BUTTON COLOR 1 = Red 2 = Black 3 = Green 4 = Yellow W CONNECTION TYPE L = Lateral P = Rear F FUNCTION (only for 2 or 3 ways) A = Normally Open C = Normally Closed 2/2 - 3/2 - Lateral connections Weight 50 g Operating force 18 N 104.T.6.22/C.L.F 2/2 - 3/2 - Rear connections Weight 50 g Operating force 18 N 104.T.6.22/C.P.F 5/2 - Lateral connections Weight 105 g Operating force 30 N 104.52.6.22/C.L 5/2 - Rear connections Weight 105 g Operating force 30 N 104.52.6.22/C.P

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 1 Air distribution Spool valves and solenoid valves 1 | 3 Series 104 - Mechanical and manual command ►Push button 2 positions (step - step) Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 90 Orifice size (mm) 2.5 Working ports size ø4 tube Coding: 104.T.6.31.W.F T TYPE 22 = 2 ways 32 = 3 ways 52 = 5 ways W CONNECTION TYPE L = Lateral P = Rear F FUNCTION (only for 2/2 and 3/2 ways) A = Normally Open C = Normally Closed 2/2 - 3/2 - Lateral connections Weight 60 g Operating force 18 N 104.T.6.31.L.F 2/2 - 3/2 - Rear connections Weight 60 g Operating force 18 N 104.T.6.31.P.F 5/2 - Lateral connections Weight 110 g Operating force 30 N 104.52.6.31.L 5/2 - Rear connections Weight 110 g Operating force 30 N 104.52.6.31.P

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 1 Air distribution Spool valves and solenoid valves 1 | 4 Series 104 - Mechanical and manual command ►Raised Push button - Spring Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 90 Orifice size (mm) 2.5 Working ports size ø4 tube Coding: 104.T.6.23/C.W.F T TYPE 22 = 2 ways 32 = 3 ways 52 = 5 ways C BUTTON COLOR 1 = Red 2 = Black 3 = Green 4 = Yellow W CONNECTION TYPE L = Lateral P = Rear F FUNCTION (only for 2 or 3 ways) A = Normally Open C = Normally Closed 2/2 - 3/2 - Lateral connections Weight 50 g Operating force 18 N 104.T.6.23/C.L.F 2/2 - 3/2 - Rear connections Weight 50 g Operating force 18 N 104.T.6.23/C.P.F 5/2 - Lateral connections Weight 105 g Operating force 30 N 104.52.6.23/C.L 5/2 - Rear connections Weight 105 g Operating force 30 N 104.52.6.23/C.P

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 1 Air distribution Spool valves and solenoid valves 1 | 5 Series 104 - Mechanical and manual command ►Palm button 2 position Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 90 Orifice size (mm) 2.5 Working ports size ø4 tube Coding: 104.T.6.25.W.F T TYPE 22 = 2 ways 32 = 3 ways 52 = 5 ways W CONNECTION TYPE L = Lateral P = Rear F FUNCTION (only for 2/2 and 3/2 ways) A = Normally Open C = Normally Closed 2/2 - 3/2 - Lateral connections Weight 65 g Operating force 19 N Emergency - Rotate to unlock 104.T.6.25.L.F 2/2 - 3/2 - Rear connections Weight 65 g Operating force 19 N Emergency - Rotate to unlock 104.T.6.25.P.F 5/2 - Lateral connections Weight 120 g Operating force 32 N Emergency - Rotate to unlock 104.52.6.25.L 5/2 - Rear connections Weight 120 g Operating force 32 N Emergency - Rotate to unlock 104.52.6.25.P

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 1 Air distribution Spool valves and solenoid valves 1 | 6 Series 104 - Mechanical and manual command ►Switch - short lever Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 90 Orifice size (mm) 2.5 Working ports size ø4 tube Coding: 104.T.F1.6.30.S.W.F2 T TYPE 22 = 2 ways 32 = 3 ways 52 = 5 ways 53 = 5 ways F1 FUNCTION (only for 5/3 ways) 32 = Open centres 33 = Pressured centres S SWITCH POSITION (only for 2/2 and 3/2 ways) 0 = 3 pos. instable 1 = 3 pos. stable W CONNECTION TYPE L = Lateral P = Rear F2 FUNCTION (only for 2/2 or 3/2 ways) A = Normally Open C = Normally Closed 2/2 - 3/2 - Lateral connections Weight 65 g Switch 2 positions stable 104.T.6.30.L.F 2/2 - 3/2 - Rear connections Weight 65 g Switch 2 positions stable 104.T.6.30.P.F 5/2 - Lateral connections Weight 120 g Switch 2 positions stable 104.52.6.30.L 5/2 - Rear connections Weight 120 g Switch 2 positions stable 104.52.6.30.P 5/3 - Lateral connections Weight 120 g 104.53.F.6.30.S.L 5/3 - Rear connections Weight 120 g 104.53.F.6.30.S.P

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 1 Air distribution Spool valves and solenoid valves 1 | 7 Series 104 - Mechanical and manual command ►Switch - long lever Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 90 Orifice size (mm) 2.5 Working ports size ø4 tube Coding: 104.T.F1.6.27.S.W.F2 T TYPE 22 = 2 ways 32 = 3 ways 52 = 5 ways 53 = 5 ways F1 FUNCTION (only for 5/3 ways) 32 = Open centres 33 = Pressured centres S SWITCH POSITION (only for 2/2 and 3/2 ways) 0 = 3 pos. instable 1 = 3 pos. stable W CONNECTION TYPE L = Lateral P = Rear F2 FUNCTION (only for 2/2 or 3/2 ways) A = Normally Open C = Normally Closed 2/2 - 3/2 - Lateral connections Weight 65 g Switch 2 positions stable 104.T.6.27.L.F 2/2 - 3/2 - Rear connections Weight 65 g Switch 2 positions stable 104.T.6.27.P.F 5/2 - Lateral connections Weight 120 g Switch 2 positions stable 104.52.6.27.L 5/2 - Rear connections Weight 120 g Switch 2 positions stable 104.52.6.27.P 5/3 - Lateral connections Weight 120 g 104.53.F.6.27.S.L 5/3 - Rear connections Weight 120 g 104.53.F.6.27.S.P

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 1 Air distribution Spool valves and solenoid valves 1 | 8 Series 104 - Mechanical and manual command ►Key switch Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 90 Orifice size (mm) 2.5 Working ports size ø4 tube Coding: 104.T.F1.6.28.S.W.F2 T TYPE 22 = 2 ways 32 = 3 ways 52 = 5 ways 53 = 5 ways F1 FUNCTION 1 (only for 5/3 ways) 32 = Open centres 33 = Pressured centres S SWITCH POSITION (only for 2/2 and 3/2 ways) 0 = 3 pos. instable 1 = 3 pos. stable W CONNECTION TYPE L = Lateral P = Rear F2 FUNCTION 2 (only for 2/2 or 3/2 ways) A = Normally Open C = Normally Closed 2/2 - 3/2 - Lateral connections Weight 100 g Switch 2 positions stable 104.T.6.28.L.F 2/2 - 3/2 - Rear connections Weight 100 g Switch 2 positions stable 104.T.6.28.P.F 5/2 - Lateral connections Weight 155 g Switch 2 positions stable 104.52.6.28.L 5/2 - Rear connections Weight 155 g Switch 2 positions stable 104.52.6.28.P 5/3 - Lateral connections Weight 155 g 104.53.F.6.28.S.L 5/3 - Rear connections Weight 155 g 104.53.F.6.28.S.P

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 1 Air distribution Spool valves and solenoid valves 1 | 9 Series 104 - Mechanical and manual command ►Lever roller - Spring Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 90 Orifice size (mm) 2.5 Working ports size ø4 tube Coding: 104.T.2.1.W.F T TYPE 22 = 2 ways 32 = 3 ways W CONNECTION TYPE L = Lateral P = Rear F FUNCTION A = Normally Open C = Normally Closed 2/2 - 3/2 - Lateral connections Weight 31 g Operating force 9 N 104.T.2.1.L.F 2/2 - 3/2 - Rear connections Weight 31 g Operating force 9 N 104.T.2.1.P.F ►Lever roller ball bearing - Spring Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 90 Orifice size (mm) 2.5 Working ports size ø4 tube Coding: 104.T.2.1/1.W.F T TYPE 22 = 2 ways 32 = 3 ways W CONNECTION TYPE L = Lateral P = Rear F FUNCTION A = Normally Open C = Normally Closed 2/2 - 3/2 - Lateral connections Weight 46 g Operating force 9 N 104.T.2.1/1.L.F 2/2 - 3/2 - Rear connections Weight 46 g Operating force 9 N 104.T.2.1/1.P.F ►Lever unidirectional - Spring Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 90 Orifice size (mm) 2.5 Working ports size ø4 tube Coding: 104.T.3.1.W.F T TYPE 22 = 2 ways 32 = 3 ways W CONNECTION TYPE L = Lateral P = Rear F FUNCTION A = Normally Open C = Normally Closed 2/2 - 3/2 - Lateral connections Weight 31 g Operating force 9 N 104.T.3.1.L.F 2/2 - 3/2 - Rear connections Weight 31 g Operating force 9 N 104.T.3.1.P.F

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 1 Air distribution Spool valves and solenoid valves 1 | 10 Series 104 - Accessories ►Complete lever roller operator Coding: 104.2.1 ►Complete lever roller ball bearing operator Coding: 104.2.1/1 ►Complete lever unidirectional Coding: 104.3.1 ►Fixing plate Coding: 104.00 ►Push button Coding: 104.6.22/C C BUTTON COLOR 1 = Red 2 = Black 3 = Green 4 = Yellow ►Raised Push button Coding: 104.6.23/C C BUTTON COLOR 1 = Red 2 = Black 3 = Green 4 = Yellow ►Push button 2 positions Coding: 104.6.31 (step - step) ►Palm button 2 position Coding: 104.6.25 Emergency - Rotate to unlock ►Switch - short lever Coding: 104.6.30.S S SWITCH POSITION (only for 3 position) 0 = 3 pos. instable 1 = 3 pos. stable Switch 2 positions stable 104.6.30 Switch 3 positions 104.6.30.S ►Switch - long lever Coding: 104.6.27.S S SWITCH POSITION (only for 3 position) 0 = 3 pos. instable 1 = 3 pos. stable Switch 2 positions stable 104.6.27 Switch 3 positions 104.6.27.S ►Key switch Coding: 104.6.28.S S SWITCH POSITION (only for 3 position) 0 = 3 pos. instable 1 = 3 pos. stable Switch 2 positions stable 104.6.28 Switch 3 positions 104.6.28.S ►Joystick selector switch Coding: 104.6.39.S ►Contact electric element Coding: 104.F F FUNCTION NO = Normally Open NC = Normally Closed ►Complete Pneumatic Operator Coding: 104.11 ►Push button protection cover Coding: 104.02

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 1 Air distribution Spool valves and solenoid valves 1 | 11 Series 104 - Pneumatic command valves ►Pneumatic - Spring Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +50 Flow rate at 6 bar with Δp=1 (Nl/min) 90 Orifice size (mm) 2.5 Working ports size ø4 tube Pilot ports size M5 Coding: 104.T.11.1.W.F T TYPE 22 = 2 ways 32 = 3 ways W CONNECTION TYPE L = Lateral P = Rear F FUNCTION A = Normally Open C = Normally Closed 2/2 - 3/2 - Lateral connections Weight 25 g Minimum piloting pressure 2,5 bar 104.22.11.1.L.F 2/2 - 3/2 - Rear connections Weight 25 g Minimum piloting pressure 2,5 bar 104.32.11.1.P.F

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice Spool valves and solenoid valves Series 105 1 Air distribution 1 | 12 Series 105 General The series 105 consist of a broad range of miniature valves and valves with various type of actuation. The connections are M5 for this series Due to their special construction with a balanced spool, these valves can be used interchangeably as 3 ways or 5 ways. The 3 ways can be used normally closed or normally open and the 5 ways can be fed through the exhausts 3 and 5 with different pressures according to the need. The spool, as it is moving, isolates the connections without being affected by the inlet pressure. Construction characteristics M5 Body Aluminium Operators Nickel plated brass Stainless steel for roller levers and button levers; Zinc plated steel for side levers; Plastic material for handles, buttons and switches Aluminium (for pneumatic command version) Seals NBR Spacer Technopolymer Spools Steel Springs Spring steel Pistons Aluminium (for pneumatic command version) Use and maintenance This valves have an average life of 15 million cycles depending on the application and air quality. Filtered and lubricated air using specified lubricants will reduce the wear of the seals and ensures long and trouble free operation. Please ensure that the valve is being used according with the manufacturers specification, such as air pressure and temperature. The exhaust port of the distributor has to be protected in a dusty and dirty environment. Repair kits including the spool complete with seals are available for overhauling the valves. However, although this is a simple operation it should be carried out by a competent person. ATTENTION: use hydraulic oil class H for lubrication such as MAGNA GC 32 (Castrol).

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 1 Air distribution Spool valves and solenoid valves 1 | 13 Series 105 - Mechanical and manual command ►Tappet panel - Spring Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 120 Orifice size (mm) 2.5 Working ports size M5 Coding: 105.T.0.1 T TYPE 32 = 3 ways 52 = 5 ways 105.32.0.1 105.52.0.1 3 ways Weight 70 g Operating force 14 N 5 ways Weight 87 g Operating force 14 N ►Lever roller - Spring Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 120 Orifice size (mm) 2.5 Working ports size M5 Coding: 105.T.2.1 T TYPE 32 = 3 ways 52 = 5 ways 105.32.2.1 105.52.2.1 3 ways Weight 85 g Operating force 6 N 5 ways Weight 102 g Operating force 6 N ►Lever roller ball bearing - Spring Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 120 Orifice size (mm) 2.5 Working ports size M5 Coding: 105.T.2.1/1 T TYPE 32 = 3 ways 52 = 5 ways 105.32.2.1/1 105.52.2.1/1 3 ways Weight 100 g Operating force 6 N 5 ways Weight 177 g Operating force 6 N

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 1 Air distribution Spool valves and solenoid valves 1 | 14 Series 105 - Mechanical and manual command ►Lever button - Spring Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 120 Orifice size (mm) 2.5 Working ports size M5 Coding: 105.T.2.6/C T TYPE 32 = 3 ways 52 = 5 ways C BUTTON COLOR 1 = Red 2 = Black 3 = Green 105.32.2.6/C 105.52.2.6/C 3 ways Weight 85 g Operating force 6 N 5 ways Weight 102 g Operating force 6 N ►Lever unidirectional - Spring Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 120 Orifice size (mm) 2.5 Working ports size M5 Coding: 105.T.3.1 T TYPE 32 = 3 ways 52 = 5 ways 105.32.3.1 105.52.3.1 3 ways Weight 85 g Operating force 6 N 5 ways Weight 102 g Operating force 6 N ►Lever panel Ø22 - 2 positions Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 120 Orifice size (mm) 2.5 Working ports size M5 Coding: 105.T.4/C T TYPE 32 = 3 ways 52 = 5 ways C LEVER COLOR 1 = Red 2 = Black 3 = Green 105.32.4/C 105.52.4/C 3 ways Weight 125 g 5 ways Weight 142 g

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 1 Air distribution Spool valves and solenoid valves 1 | 15 Series 105 - Mechanical and manual command ►Lever panel Ø30 - 2 positions Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 120 Orifice size (mm) 2.5 Working ports size M5 Coding: 105.T.5/C T TYPE 32 = 3 ways 52 = 5 ways C LEVER COLOR 1 = Red 2 = Black 3 = Green 105.32.5/C 105.52.5/C 3 ways Weight 165 g 5 ways Weight 182 g ►Push button Ø30 - Spring Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 120 Orifice size (mm) 2.5 Working ports size M5 Coding: 105.T.6.1/C T TYPE 32 = 3 ways 52 = 5 ways C BUTTON COLOR 1 = Red 2 = Black 3 = Green 105.32.6.1/C 105.52.6.1/C 3 ways Weight 123 g Operating force 14 N 5 ways Weight 140 g Operating force 14 N ►Push button Ø22 - Spring Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 120 Orifice size (mm) 2.5 Working ports size M5 Coding: 105.T.6.2/C T TYPE 32 = 3 ways 52 = 5 ways C BUTTON COLOR 1 = Red 2 = Black 3 = Green 105.32.6.2/C 105.52.6.2/C 3 ways Weight 102 g Operating force 14 N 5 ways Weight 119 g Operating force 14 N

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 1 Air distribution Spool valves and solenoid valves 1 | 16 Series 105 - Mechanical and manual command ►Push button - Spring Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 120 Orifice size (mm) 2.5 Working ports size M5 Coding: 105.T.6.22/C T TYPE 32 = 3 ways 52 = 5 ways C BUTTON COLOR 1 = Red 2 = Black 3 = Green 4 = Yellow 105.32.6.22/C 105.52.6.22/C 3 ways Weight 165 g Operating force 14 N 5 ways Weight 182 g Operating force 14 N ►Raised Push button - Spring Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 120 Orifice size (mm) 2.5 Working ports size M5 Coding: 105.T.6.23/C T TYPE 32 = 3 ways 52 = 5 ways C BUTTON COLOR 1 = Red 2 = Black 3 = Green 4 = Yellow 105.32.6.23/C 105.52.6.23/C 3 ways Weight 170 g Operating force 14 N 5 ways Weight 187 g Operating force 14 N ►Switch 2 positions Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 120 Orifice size (mm) 2.5 Working ports size M5 Coding: 105.T.6.27 T TYPE 32 = 3 ways 52 = 5 ways 105.32.6.27 105.52.6.27 3 ways Weight 185 g 5 ways Weight 202 g

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 1 Air distribution Spool valves and solenoid valves 1 | 17 Series 105 - Mechanical and manual command ►Key switch 2 positions Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 120 Orifice size (mm) 2.5 Working ports size M5 Coding: 105.T.6.28 T TYPE 32 = 3 ways 52 = 5 ways 105.32.6.28 105.52.6.28 3 ways Weight 215 g 5 ways Weight 232 g ►Palm pushbutton Ø30 - Spring Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 120 Orifice size (mm) 2.5 Working ports size M5 Coding: 105.T.7.1/C T TYPE 32 = 3 ways 52 = 5 ways C BUTTON COLOR 1 = Red 2 = Black 3 = Green 105.32.7.1/C 105.52.7.1/C 3 ways Weight 126 g Operating force 14 N 5 ways Weight 143 g Operating force 14 N ►Palm pushbutton Ø22 - Spring Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 120 Orifice size (mm) 2.5 Working ports size M5 Coding: 105.T.7.2/C T TYPE 32 = 3 ways 52 = 5 ways C BUTTON COLOR 1 = Red 2 = Black 3 = Green 105.32.7.2/C 105.52.7.2/C 3 ways Weight 103 g Operating force 14 N 5 ways Weight 120 g Operating force 14 N

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 1 Air distribution Spool valves and solenoid valves 1 | 18 Series 105 - Mechanical and manual command ►Push button Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 120 Orifice size (mm) 2.5 Working ports size M5 Coding: 105.T.8.1/C T TYPE 32 = 3 ways 52 = 5 ways C BUTTON COLOR 1 = Red 2 = Black 3 = Green 105.32.8.1/C 105.52.8.1/C 3 ways Weight 75 g Operating force 14 N 5 ways Weight 92 g Operating force 14 N ►Push button 2 positions Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 120 Orifice size (mm) 2.5 Working ports size M5 Coding: 105.T.8/C T TYPE 32 = 3 ways 52 = 5 ways C BUTTON COLOR 1 = Red 2 = Black 3 = Green 105.32.8/C 105.52.8/C 3 ways Weight 75 g Operating force 14 N 5 ways Weight 92 g Operating force 14 N ►Whisker - Spring Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 120 Orifice size (mm) 2.5 Working ports size M5 Coding: 105.T.9.1 T TYPE 32 = 3 ways 52 = 5 ways 105.32.9.1 105.52.9.1 3 ways Weight 136 g 5 ways Weight 153 g

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 1 Air distribution Spool valves and solenoid valves 1 | 19 Series 105 - Mechanical and manual command ►Handle with valve Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 120 Orifice size (mm) 2.5 Working ports size M5 - Quick Fitting for Ø4 tube Coding: 105.T.6.A.F T TYPE 32 = 3 ways 52 = 5 ways A FEEDING 40 = Left feeding 40D = Right feeding F FUNCTION (only for 3 ways) A = Normally Open C = Normally Closed Weight 165 g Operating force 14 N 105.32.6.40.F Left feeding Weight 190 g Operating force 14 N 105.52.6.40 Right feeding Weight 190 g Operating force 14 N 105.52.6.40.D

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice 1 Air distribution Spool valves and solenoid valves 1 | 20 Series 105 - Pneumatic command valves ►Pneumatic - Spring Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 120 Orifice size (mm) 2.5 Working ports size M5 Pilot ports size M5 Coding: 105.T.11.1 T TYPE 32 = 3 ways 52 = 5 ways 105.32.11.1 105.52.11.1 3 ways Weight 90 g Minimum piloting pressure 2,5 bar 5 ways Weight 100 g Minimum piloting pressure 2,5 bar ►Pneumatic - Differential external Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 120 Orifice size (mm) 2.5 Working ports size M5 Pilot ports size M5 Coding: 105.T.11.12 T TYPE 32 = 3 ways 52 = 5 ways 105.32.11.12 105.52.11.12 3 ways Weight 110 g Minimum piloting pressure 2,5 bar 5 ways Weight 120 g Minimum piloting pressure 2,5 bar ►Pneumatic - Pneumatic Operational characteristics Fluid Filtered air. No lubrication needed, if applied it shall be continuous Max working pressure (bar) 10 Temperature °C -5 ÷ +70 Flow rate at 6 bar with Δp=1 (Nl/min) 120 Orifice size (mm) 2.5 Working ports size M5 Pilot ports size M5 Coding: 105.T.11.11 T TYPE 32 = 3 ways 52 = 5 ways 105.32.11.11 105.52.11.11 3 ways Weight 110 g Minimum piloting pressure 2,5 bar 5 ways Weight 120 g Minimum piloting pressure 2,5 bar

Overall dimensions and technical information are provided solely for informative purposes and may be modified without notice Spool valves and solenoid valves Series 200 1 Air distribution 1 | 21 Series 200 General The series 200 consist of a broad range of valves with various type of actuation. The connections for this series are from G 1/8" to G 1". Due to their special construction with a balanced spool, these valves can be used interchangeably as 3 ways or 5 ways. The 3 ways can be used normally closed or normally open and the 5 ways can be fed through the exhausts 3 and 5 with different pressures according to the need. The spool, as it is moving, isolates the connections without being affected by the inlet pressure. Construction characteristics G 1/8" - G 1/4" - G 1/2" - G 1" Body Aluminium Operators Aluminium Technopolymer Seals NBR PUR for 212/2 Spacer Technopolymer Aluminium for G1" (211) Spools Steel Aluminium, for 212/2 Springs Spring steel Pistons Technopolymer, for 228 pneumatic command valves Aluminium, for 224, 212, 212/2 e 211 pneumatic command valves Use and maintenance This valves have an average life of 15 million cycles depending on the application and air quality. Filtered and lubricated air using specified lubricants will reduce the wear of the seals and ensures long and trouble free operation. Please ensure that the valve is being used according with the manufacturers specification, such as air pressure and temperature. The exhaust port of the distributor has to be protected in a dusty and dirty environment. Repair kits including the spool complete with seals are available for overhauling the valves. However, although this is a simple operation it should be carried out by a competent person. ATTENTION: use hydraulic oil class H for lubrication such as MAGNA GC 32 (Castrol).
